Description
Out1
| DC Voltage | 12V-15V |
| Rated Current(220V input) | 267A |
| Ripple & Noise | <1% |
| Line Regulation | <1% |
| Load Regulation | <1% |
| Setup Time | <14S |
| Short Circuit Protection | >10mS |
Out2
| DC Voltage | 12.3V |
| Rated Current(220V input) | 18A |
| Ripple & Noise | <1% |
| Voltage Accuracy | 12.2V—12.4V |
| Line Regulation | <1% |
| Load Regulation | <1% |
| Setup Time | <10S |
| Short Circuit Protection | >10mS |
Input
| Voltage Range | 220-277V AC |
| Frequency Range | 50-60Hz |
| Power Factor | >0.99(full load) |
| Leakage Current | <4mA（220V 50Hz） |
Protection
| Input low-voltage protection value | 185-195V AC |
| Output Short Circuit | Yes |
| Overheat Protection | Yes |
| Over-current Output | 280A-402A（protection value varies under different voltage） |
Environment
| Operating Temperature | -20-40℃ |
| Operating Humidity | 20%-90%RH（non–condensing） |
| Altitude | < 2000m |
Structure
| Dimensions | 254.6*251.6*63mm |
| Net Weight | 3.9Kg |
| Cooling System | Forced‐air cooling |
| Noise | 45dBA |
